● Unique positive protection management design
● Same port design for sampling, charging and discharging
● High-precision battery cell voltage sampling (error margin ≤5mV/cell)
● High-precision current detection (<±1A@100A range)
● Unique SOC and SOH algorithm
● Two modes of charging and static balance (balance current≤150mA)
● Integrated 40A current limiting module, active and passive modes are optional
● Ultra-low sleep power consumption (<10uA)
● Communication: RS485/RS232/ (support 4 groups in series)
● Built-in pre-charge function
● Support 0-150A charge and discharge
● Visualization of function switch options
Limited current version:160mm*90mm*17mm
The five layers of reliable protection from design, testing, materials, production technology and processing flow in household energy storage make every battery safe, reliable and durable.
